Silicate phosphors for backlight
Category:
Phosphors for Backlight
Owing to the high quantum yield, excellent deterioration resistance performance and good quality stability, the silicate system (BOSE) phosphors for backlight using effectively guarantee the strict requirements of backlight lamp beads on light efficiency, color matching and yield.
|
Model |
Peak Wavelength/nm |
Dominant Wavelength/nm |
Full Width at Half Maximum/nm |
CIE（x, y） |
D50/μm |
|
SC550X |
565.6±0.2 |
550.8±1.0 |
86.9±0.5 |
(0.406, 0.565) |
15.8±1.0 |
|
SC562X |
571.4±0.2 |
561.8±1.0 |
95.3±0.5 |
(0.448, 0.535) |
17.5±1.5 |
|
SC567X |
573.3±0.2 |
564.9±1.0 |
96.2±0.5 |
(0.462, 0.524) |
20.9±1.5 |
Emission Spectrum and Micromorphology of BOSE Phosphor for Backlight Module Silicate Phosphors for Backlight
